TCTempX8

TCTempX (TCTempX8)

The TCTempX Series includes 4, 8, 12, and 16-channel thermocouple-based temperature data loggers. Includes ISO17025 accredited calibration certificate.

Solicitar cotaçãoBaixar ficha técnica

TCTempX (TCTempX8)

Key Features

  • Accepts a Variety of Thermocouples
  • Large Memory Capacity
  • Individual Cold Junction Compensation
TCTempX (TCTempX8)

Description

The TCTempX Series includes the TCTempX4, TCTempX8, TCTempX12 and TCTempX16 thermocouple-based temperature data loggers with a reading rate of up to 4 Hz, ideal for a variety of applications, whether it is remote temperature monitoring or multiple points in a central location.

In addition to having a large memory capacity, the TCTempX allows users to disable channels to further maximize memory capacity. For easy identification, each channel can be named with up to a ten-digit title.

In addition, the TCTempX Series features individual cold junction compensation for each channel providing increased accuracy and response time, and if a probe is removed or severed during logging, the software automatically annotates the data.

The TCTempX Series is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

Replacement product for the QuadTemp and OctTemp

TCTempX (TCTempX8)

General

Memory4-channel: 524,032 readings; 8-channel: 262,016 readings; 12-channel: 174,677 readings; 16-channel: 131,008 readings
Reading Rate4 Hz up to 1 reading every 24 hours
Cold Junction CompensationAutomatic, based on internal channel
Channels4, 8, 12, 16
Battery Life18 months typical
MaterialBlack anodized aluminum
Dimensions4-channel: 2.70 in x 7.25 in x 1.22 in; (65.6 mm x 184.2 mm x 31.0 mm); 8-channel: 2.70 in x 7.25 in x 1.22 in; (65.6 mm x 184.2 mm x 31.0 mm); 12-channel: 2.70 in x 7.25 in x 1.68 in; (65.6 mm x 184.2 mm x 42.7 mm); 16-channel: 2.70 in x 7.25 in x 2.14 in; (65.6 mm x 184.2 mm x 54.4 mm)
Operating Environment-20 ºC to +60 ºC (-4 ºF to +140 ºF),; 0 %RH to 95 %RH non-condensing
ApprovalsCE

Temperature

Internal Channel Temperature Resolution0.01 °C (0.018 °F)
Remote Channel Temperature SensorThermocouple Types J, K, T, E, R, S, B, N
Remote Channel Temperature RangeThermocouple Dependent
Remote Channel Temperature ResolutionThermocouple Dependent
Remote Channel Temperature Calibrated AccuracyThermocouple Dependent
