PTB110
PTB110 Barometer
for industrial use
Request a quoteDownload the datasheet
Vaisala BAROCAP® Barometer PTB110 is designed both for accurate barometric pressure measurements at a room temperature and for general environmental pressure monitoring over a wide temperature range. The compact PTB110 is suitable for applications, such as environmental pressure monitoring, data buoys, laser interferometers, and in agriculture and hydrology. Due to its very low power consumption, the barometer is particularly ideal for different data logger applications.
Features
Vaisala BAROCAP® sensor Several pressure ranges Accuracy ±0.3 hPa at +20 °C Long-term stability Output voltage 0 ... 2.5 or 0 ... 5 VDC On/off control with external trigger Output voltage 0 ... 2.5 or 0 ... 5 VDC Current consumption less than 4 mA Mountable on a (35 mm wide) DIN rail
Configure the instrument
Choose the model, probes and accessories. Incompatible combinations are blocked as you go; the remaining rules are checked when the instrument is added to the quote.
Loading the options…
PTB110
A code can be pasted and the configuration builds itself.
Services and accessories
They are quoted separately: the instrument need not be configured.
Key benefits
Excellent long-term stability of the barometer
The PTB110 barometer uses the Vaisala BAROCAP® Sensor, a silicon capacitive absolute pressure sensor developed by Vaisala for barometric pressure measurement applications. The sensor combines the outstanding elasticity characteristics and mechanical stability of single-crystal silicon with the proven capacitive detection principle.
Accuracy and stability
The excellent long-term stability of the barometer minimizes or even removes the need for field adjustment in many applications, such as environmental pressure monitoring, data buoys, laser interferometers, and in agriculture and hydrology.
Low power consumption
The compact PTB110 is especially ideal for data logger applications as it has low power consumption. Also an external On/Off control is available. This is practical when the supply of electricity is limited.
Documents
- DatasheetVaisala BAROCAP® Barometer PTB110 is designed both for accurate barometric pressure measurements at room temperature and for general environmental pressure monitoring over a wide temperature range.
- User guidePTB110 provides accurate barometric pressure measurements at a room temperature and for general environmental pressure monitoring over a wide temperature..
