Overview
R02 Label Editor is a proprietary application of RADWAG, which allows users to make labels forindustry scales, scales intended for EX area, PGC scales and checkweighers. It is used to design labels for scales operating in labelling, counting, dosing and formula making systems, and in automatic scale systems.
R02 Label Editor is compatible with:
- advanced C32, HX7 and HX5.EX series scales,
- professional HY10, TMX, WLY, WPY and 5Y series scales,
- DWM, DWT and DWR series checkweighers.
Label Editor functionality:
- making label templates for ZEBRA label printers that support EPL-II and ZPL-II programming languages,
- making label templates for CAB Hermes printers,
- sending graphics and fonts to printer memory,
- change of DPI for the designed label,
- change of label size and label print direction,
- declaring label printout quantity,
- support of code pages: WE – Windows 3.1 Latin 2, E1 – ISO 8859/1: Latin 1, PM – PC-850 Multilingual,
PE – PC-852 Latina 2, PC – PC-8 Code Page 437, E7 – ISO 8859/7 Latin/Greek, WR – Cyryllic and WL – Windows-125, - available label components: graphics, bar code, line, frame, table, nutrition facts label, static text, variable value,
- support of 1D bar codes: Code 3 of 9, UPC-A, UPC-E, Interleaved 2 of 5, Interleaved 2 of 5 Check Digit, Code 128 A,
Code 128 B, Code 128 C, GS1-128, EAN-13 (JAN-13), EAN-8 (JAN-8), HIBC, CODEBAR (NW-7), Int 2 of 5, Plessey, UPC 2DIG ADD, UPC 5DIG ADD, Code 93, UCC/EAN128, UCC/EAN128 for K-MART and UCC/EAN128 Random Weight, - support of 2D bar codes: UPS MaxiCode, PDF417 and DataMatrix,
- selection between 13 different graphic styles.
