SPMK213B

SPMK213B Low Pressure Pump

SPMK213B pressure calibration pump is pneumatic handle pressure generator. It provides stable low pressure from -0.95 to 6bar (-14-90psi). Its Hard oxidation treatment makes it wear-resistant and scratch-resistant. The simple structure and easy operation make it a perfect equipment for calibrating low pressure gauges, pressure transmitters, pressure sensors, and other low pressure (vacuum) instruments.

Request a quote

SPMK213B Low Pressure Pump
  • Perfect pressure stability
  • Light weight, easy for filed and lab usage

Feature

  • Pressure range -0.95-6bar (-14-90psi)
  • Quick connector makes it easy and fast to connect the under tested device
  • Light weight, good for both on-site and Lab usage
  • Fine adjustment screw of 1Pa
  • Hard oxidation treatment, wear-resistant, scratch-resistant.
SPMK213B Low Pressure Pump

Specifications

MediaAir
Pressure range-0.95-6bar; -14-90psi
ConnectionM20*1.5, 1/4NPT, 1/4BSP, 1/2NPT, 1/2BSP Female. Please confirm 1 or 2 thread type from above. M20*1.5, 1/4NPT, 1/4BSP, 1/2NPT, 1/2BSP Female. Please confirm 1 or 2 thread type from above.
Dimension298*179*154mm
Weight2.6kg
AccessoriesUser’s manual, Plugs, O rings
PackageCarton box + Thicken foam (Aluminum or Trolley case are optional and cost extra)
ShippingBy air express
