SPMK214E

SPMK214E Pneumatic Pressure Pump 160bar ((-0.95-160)bar Air Media 6.5kg)

SPMK214E pressure calibration pump is high pressure pneumatic type. It provides stable high pressure from -0.95 to 160bar (-14-2320psi). The hard oxidation treatment makes it wear-resistant and scratch-resistant. The special structure makes it easier to generate high pressure up to 2320psi. It is a perfect equipment for calibrating pressure gauges, pressure transmitters, pressure sensors, and other pressure (vacuum) instruments.

Request a quote

SPMK214E Pneumatic Pressure Pump 160bar ((-0.95-160)bar Air Media 6.5kg)

Feature

  • Pressure range -0.95 to 160bar (-14-2320psi)
  • Perfect pressure stability
  • Hand tight quick connector, easy to connect the under tested device
  • Special structure makes easy to reach high pressure
  • Fine adjustment screw of 1Pa
  • Hard oxidation treatment, wear-resistant, scratch-resistant.
SPMK214E Pneumatic Pressure Pump 160bar ((-0.95-160)bar Air Media 6.5kg)

Specifications

MediaAir
Pressure range-0.95 - 160bar; -14-2320psi
ConnectionM20*1.5, 1/4NPT, 1/4BSP, 1/2NPT, 1/2BSP Female. Please confirm 1 or 2 thread type from above.
Dimension470*262*170mm
Weight6.0kg
AccessoriesUser’s manual, Plugs, O rings
PackageCarton box + Thicken foam (Aluminum or Trolley case are optional and cost extra)
ShippingBy air express
